    2 Core Low Voltage Copper Power Cable, PVC Insulated Electrical Wire for Construction

    Full range of products can be customized
    Our 2 Core Low Voltage Flexible Cable (RVV) consists of two independent insulated stranded copper conductors, wrapped with integrated PVC outer sheath. Rated voltage 300/500V, designed for low voltage power supply and signal transmission.
    We adopt high-purity oxygen-free stranded copper as conductor, featuring excellent electrical conductivity, low heat generation and stable current transmission. Inner PVC insulation delivers reliable dielectric performance to prevent short circuit and leakage. The outer PVC sheath offers good resistance against abrasion, moisture and mild chemical corrosion.
    This two-core cable has outstanding flexibility, easy to bend and route through conduits, equipment cabinets and narrow spaces. Suitable for fixed indoor wiring and occasional moving connection. Various cross-section options from 0.5mm² up to 16mm² meet different current load demands. Custom cable length, sheath color and printing are supported for bulk orders.

    • Clear shipment tracking

    • Rigorous quality inspection

    • Has good after-sales service

    Inquire Now
    Whatsapp

    Share:

    Detailed Description

    Product Feature

    ✅ 2 Core Stranded Oxygen-Free Copper Conductor, Excellent Conductivity

    ✅ PVC Insulation + PVC Outer Sheath

    ✅ Good Flexibility, Easy Installation & Bending

    ✅ Anti-abrasion, Moisture-proof & Anti-aging Performance

    ✅ Multiple sheath color optional: Black, White, Grey

    ✅ Support custom length marking & outer surface printing

    ✅ Flame retardant option available upon request

    ✅ Compliant with relevant IEC & CE standards

    Technical Specifications of 2 Core Low Voltage Copper Power Cable

    ItemSpecification
    ModelRVV 2 Core Flexible Cable
    Rated Voltage300/500V
    Conductor MaterialOxygen-free Stranded Copper
    Insulation MaterialPVC Compound
    Outer Sheath MaterialPVC
    Structure2 Cores, Multi-strand Flexible Conductor
    Standard Cross Sections(mm²)0.5, 0.75, 1.0, 1.5, 2.5, 4, 6, 10, 16
    Sheath ColorBlack / White / Grey (Optional)
    Operating Temperature-15℃ ~ +70℃
    Installation ConditionIndoor laying, suitable for conduit & equipment internal wiring
    CharacteristicFlexible, Anti-abrasion, Moisture Resistant, Anti-aging
    Flame RetardantOptional upon requirement
    PackagingStandard Wooden Drum / Plastic Roll
    Custom ServiceCustom length, surface printing, color available
    ComplianceCE, IEC Standard

    Why Choose Yiyue

    1.Strict raw material inspection, pure copper without recycled aluminum mixing

    2.Stable outer diameter, uniform insulation thickness，consistent quality per roll

    3.Exact meter count, avoid shortage length common in market low-grade cables

    4.Flexible production, support small MOQ and customized specifications

    5.Anti-tangle standard packaging, convenient for construction laying

    6.Technical support for cable selection according to load distance

    Packaging And Transportation

    Yiyue Electric implements standardized packaging and shipping management to protect transformers, switchgears, cables and electrical components throughout the entire delivery process, ensuring products arrive in intact condition.

    Customized Packaging Solutions

    • Small-sized products: Moisture-proof bubble wrap + reinforced cartons with anti-collision corner protectors
    • Medium & large equipment: Stretch film sealing for full moisture resistance, with foam padding on vulnerable parts for shock absorption
    • Heavy machinery & export shipments: ISPM15-compliant fumigated wooden cases secured with steel belts, suitable for long-distance international transit

    All packages are marked with clear shipping marks and handling warnings for standard operation.

    Production Lead Time

    • Standard in-stock items: 5–7 working days upon payment confirmation
    • Customized non-standard products: 7–15 working days after design confirmation & deposit
    • Large orders with special requirements: Lead time subject to separate confirmation
    Shipping MethodRegionEstimated Transit TimeRemarks
    Sea FreightSoutheast Asia15–25 working daysPort to port, FCL & LCL available
    Middle East15–25 working daysPort to port, FCL & LCL available
    North America20–30 working daysPort to port, FCL & LCL available
    Europe25–35 working daysPort to port, FCL & LCL available
    Oceania20–30 working daysPort to port, FCL & LCL available
    Africa30–45 working daysPort to port, FCL & LCL available
    Air FreightSoutheast Asia5–7 working daysAirport to airport, for urgent orders
    Middle East5–7 working daysAirport to airport, for urgent orders
    North America10–15 working daysAirport to airport, for urgent orders
    Europe7–15 working daysAirport to airport, for urgent orders
    Africa4–6 working daysAirport to airport, for urgent orders
    Air Freight (Express)Worldwide Major Countries3–7 working daysDoor-to-door, suitable for small spare parts
    Applications
    FAQs

    Tags:

    2 Core Low Voltage Copper Power Cable 2 Core Low Voltage Copper Power Cable for Construction Low Voltage Copper Power Cable
