    Compact 24kV Gas Insulated RMU Modular SF6 Inflatable Cabinet Indoor Distribution Switchgear

    A professional electrical engineering team offers a comprehensive and customizable one-stop service covering all categories.

    24kV SF6 Gas Insulated Ring Main Unit (RMU / Inflatable Cabinet) is indoor medium voltage fully sealed modular switchgear applied for 24kV three-phase AC 50Hz secondary distribution network. All primary live components, busbars and switching elements are hermetically sealed inside stainless steel gas tank filled with SF6 gas, achieving IP67 protection for the gas compartment.
    Adopting compact modular design, it can be freely combined with load break switch, earthing switch, fuse combination or vacuum circuit breaker (VCB) according to project demands. Free from influence of humidity, dust, condensation and altitude variation, the equipment features long service cycle and nearly maintenance-free operation.

    It is widely adopted in urban ring power grid, compact prefabricated substation, commercial complex, industrial park, solar & wind power station, mining and real estate distribution system. The whole design complies with IEC 62271 series standards.

    • Clear shipment tracking

    • Rigorous quality inspection

    • Has good after-sales service

    Inquire Now
    Whatsapp

    Share:

    Detailed Description

    Product Feature

    ✅ Fully welded stainless steel gas tank, primary components reach IP67 protection level

    ✅ SF6 gas used for insulation and arc extinction, stable dielectric performance

    ✅ Compact modular structure, flexible combination for different switching schemes

    ✅ Complete mechanical interlock device to avoid dangerous misoperation

    ✅ Indoor outer cabinet with IP4X protection for operator safety

    ✅ Support configuration of load break switch or vacuum circuit breaker(VCB)

    ✅ Designed and tested in accordance with IEC 62271 standards, OEM customization supported

    Technical Specifications of 24kV Gas Inflatable Cabinet

    ItemSpecification
    Rated Voltage24kV
    Rated Frequency50Hz
    Rated Current630A / 1250A Optional
    Rated Short-time Withstand Current20kA / 25kA (3s)
    Gas Compartment ProtectionIP67
    Outer Cabinet ProtectionIP4X
    Switch Type3-position Load Break Switch / VCB Optional
    Insulating & Arc Extinguishing MediumSF6 Gas
    Installation ConditionIndoor
    Working Altitude≤1000m (high altitude customized available)
    Ambient Temperature-25℃ ~ +40℃
    Executive StandardIEC 62271
