    Indoor GCS Draw-out Low Voltage Switchgear Modular Power Distribution Cabinet IEC Standard

    A professional electrical engineering team offers a comprehensive and customizable one-stop service covering all categories.

    GCS low voltage withdrawable switchgear (MCC Motor Control Center Cabinet) applies to indoor three-phase AC 50/60Hz low voltage power system with rated voltage 400/690V. It is mainly used for power distribution, centralized motor control and reactive power compensation.
    Adopting modular drawer withdrawable structure, functional drawers own excellent interchangeability with three working positions: Connection, Test and Disconnection. Independent compartment layout including busbar chamber, functional unit chamber and cable compartment improves equipment safety. It supports quick replacement of drawer units without whole panel power cut, greatly shortening maintenance downtime.

    Widely used in power plants, petrochemical industry, metallurgy, industrial parks, commercial buildings, photovoltaic energy storage stations and automated production lines. The design complies with IEC 61439 standards.

    • Clear shipment tracking

    • Rigorous quality inspection

    • Has good after-sales service

    Inquire Now
    Whatsapp

    Share:

    Detailed Description

    Product Feature

    ✅ Modular withdrawable drawer design, strong interchangeability of functional units

    ✅ Three-position mechanism: Connection / Test / Disconnection with clear position indication

    ✅ Complete mechanical interlock system to prevent dangerous misoperation

    ✅ Independent partition structure: busbar compartment, drawer compartment, cable compartment

    ✅ Convenient hot-swap maintenance, reduce system outage time

    ✅ High-density layout, save installation space for multiple motor loops

    ✅ Flexible combination for incoming, feeder, motor control and capacitor compensation circuits

    Technical Specifications of GCS Low Voltage Switchgear

    ItemSpecification
    ModelGCS Low Voltage Withdrawable Switchgear (MCC Cabinet)
    Rated Insulation VoltageAC 690V
    Rated Operating VoltageAC 400V
    Rated Frequency50Hz / 60Hz
    Rated Current of Main Busbar≤4000A
    Rated Current of Drawer Unit≤400A
    Rated Short-time Withstand Current30kA / 1s, 50kA / 0.5s Optional
    Protection DegreeIP30 (Indoor)
    Structure TypeModular withdrawable drawer type
    Installation EnvironmentIndoor, no flammable, explosive corrosive gas
    Ambient Temperature-5℃ ~ +40℃
    Executive StandardIEC 61439

    Why Choose Yiyue
    1.Professional manufacturer for low voltage complete switchgear, strict assembly inspection before delivery.

    2.Provide one-line diagram, dimension drawing, wiring drawing and operation manual for project bidding.

    3.Flexible customization on cabinet size, layout, component brand, surface color and secondary circuit.

    4.Stable production schedule for industrial EPC and bulk container orders. Experienced engineering team

    5.supports parameter matching and technical scheme communication.

    6.Factory direct supply with competitive price, support OEM & ODM service.
