Product Feature
✅High‑purity aluminum conductor, excellent electrical conductivity, lightweight for easy handling & installation.
✅XLPE cross‑linked polyethylene insulation, high heat resistance, stable electrical performance
✅PVC outer sheath, anti‑aging, good resistance to corrosion and environmental damage
✅Suitable for duct, overhead and indoor laying, not for direct underground burial
✅Low comprehensive cost, cost‑effective for industrial & building power distribution projects
✅Strictly manufactured to international industry standards, stable long‑term operation
✅Widely used in municipal engineering, factory power supply, residential area power distribution
Technical Specifications of 4 Core Low Voltage Aluminum Power Cable
| 标称截面 (mm²) | 绝缘厚度 (mm) | 护套厚度 (mm) | 近似外径 (mm) | 近似重量 (kg/km) | 20℃导体最大直流电阻 (Ω/km) | 空气中载流量 (A) | 直埋土壤载流量 (A) |
|---|---|---|---|---|---|---|---|
| 4×2.5 | 0.7 | 1.8 | 12.1 | 132 | 12.10 | 26 | 20 |
| 4×4 | 0.7 | 1.8 | 13.2 | 162 | 7.41 | 34 | 27 |
| 4×6 | 0.7 | 1.8 | 14.5 | 202 | 4.61 | 43 | 35 |
| 4×10 | 0.7 | 1.8 | 17.8 | 331 | 3.08 | 57 | 66 |
| 4×16 | 0.7 | 1.8 | 20.5 | 434 | 1.91 | 74 | 85 |
| 4×25 | 0.9 | 1.8 | 23.9 | 602 | 1.20 | 99 | 110 |
| 4×35 | 0.9 | 1.8 | 26.3 | 751 | 0.868 | 119 | 130 |
| 4×50 | 1.0 | 1.8 | 30.1 | 917 | 0.641 | 148 | 160 |
| 4×70 | 1.1 | 1.9 | 34.4 | 1322 | 0.443 | 188 | 195 |
| 4×95 | 1.1 | 2.0 | 38.8 | 1780 | 0.320 | 233 | 235 |
| 4×120 | 1.2 | 2.1 | 42.9 | 2147 | 0.253 | 273 | 265 |
| 4×150 | 1.4 | 2.3 | 47.9 | 2674 | 0.206 | 307 | 300 |
| 4×185 | 1.6 | 2.4 | 52.9 | 3308 | 0.164 | 359 | 340 |
| 4×240 | 1.7 | 2.6 | 59.3 | 4228 | 0.125 | 427 | 395 |
| 4×300 | 1.8 | 2.8 | 65.5 | 5200 | 0.100 | 495 | 445 |
Why Choose Yiyue
One‑stop sourcing for full‑range electrical equipment: transformers, switchgears, box substations, EV chargers, generators, power cables and complete power distribution solutions.
Strong OEM & ODM customization: adapt to local voltage, frequency, IP rating, high‑temperature / salt‑fog harsh working conditions for global projects.
Strict factory‑level testing: every unit undergoes full inspection before delivery for stable performance in tough site environments.
Direct factory supply: competitive price without middle‑man markup, ideal for bulk project orders.
Professional foreign trade technical support: fast quotation, drawing support, certification documents, complete customs‑clearance papers and remote after‑sales guidance.
Rich overseas project experience: provide practical power distribution solutions for infrastructure, commercial‑industrial and new‑energy projects worldwide.
Yiyue Electric implements standardized packaging and shipping management to protect transformers, switchgears, cables and electrical components throughout the entire delivery process, ensuring products arrive in intact condition.
Customized Packaging Solutions
All packages are marked with clear shipping marks and handling warnings for standard operation.
Production Lead Time
| Shipping Method | Region | Estimated Transit Time | Remarks |
| Sea Freight | Southeast Asia | 15–25 working days | Port to port, FCL & LCL available |
| Middle East | 15–25 working days | Port to port, FCL & LCL available | |
| North America | 20–30 working days | Port to port, FCL & LCL available | |
| Europe | 25–35 working days | Port to port, FCL & LCL available | |
| Oceania | 20–30 working days | Port to port, FCL & LCL available | |
| Africa | 30–45 working days | Port to port, FCL & LCL available | |
| Air Freight | Southeast Asia | 5–7 working days | Airport to airport, for urgent orders |
| Middle East | 5–7 working days | Airport to airport, for urgent orders | |
| North America | 10–15 working days | Airport to airport, for urgent orders | |
| Europe | 7–15 working days | Airport to airport, for urgent orders | |
| Africa | 4–6 working days | Airport to airport, for urgent orders | |
| Air Freight (Express) | Worldwide Major Countries | 3–7 working days | Door-to-door, suitable for small spare parts |
